Industrial Laser Distance Sensors
J5AJ0-50 is a laser ranging module based on the direct time-of-flight (d-ToF) principle. This module provides a compact solution for high-precision distance sensing in the market. By leveraging the independently developed SPAD (Single Photon Avalanche Diode) and unique ToF acquisition algorithm, integrating VCSEL and MCU technologies, J5AJ0-50 can achieve precise distance measurement up to 50 meters. The measurement data and system configuration information are transmitted via UART.
| 1.Product technical specifications | |
|---|---|
| Technical Specifications | Parameters |
| Measurement range | 0.08~50m @80klux; indoor 0.08~60m |
| Distance measurement accuracy | ±3cm（＜ 3m） ； 1% (≥3m） ① |
| Repeatability accuracy | ± 10mm（ ＜3m ） ； ± 30mm（3m-50m ） |
| Distance measurement resolution | 1mm |
| Optical wavelength | 905nm |
| Frequency | 3/30/50/100/300/500Hz |
| Laser spot size | 5cm@5m； 20cm@20m；40cm@40m |
| Operating voltage | 4.5~5.5V |
| Product power consumption | <90mA@5V |
| Peak optical power | < 9W |
| MCU interface | UART |
| Shell material Module size | Metal |
| Module weight | 17.3*17*12mm |
| Anti-environmental light Working temperature | 5g |
| Measurement range | > 40m@100klux @3hz② |
| Distance measurement accuracy | （-20 ~ 65） °C |
| Note 1: This parameter was measured at 25℃ , in an indoor environment, with a 90% reflective surface. |
|
| Note 2: This parameter was measured under an outdoor temperature of 25℃ and in an ambient environment. |
|
